A general guide for cutting conditions for different combinations of materials and blades is given be-
low. Before cutting, perform a cutting test with a suitable blade for the sheet material.
IMPORTANT
Blades have suitability for particular sheet materials, and cutting materials that are not specified as suitable may
cause the blade to break.
Blade
Material Cutting force (gf)
Cutting speed (cm/
sec)
*1
Amount of blade
offset (mm)
ZEC-U5032
General Signage Vinyl 30 to 100
30 or less 0.25General inkjet vinyl 50 to 100
Iron-on print vinyl 50 to 100
ZEC-U5025
General Signage Vinyl 40 to 100 30 or less
0.25
Fluorescent Vinyl 120 to 200 10 or less
ZEC-U5010 Glass (car) film 80 to 120 30 or less 0.50
ZEC-U1715 Sandblast 100 to 150 5 or less 0.25
ZEC-U3050
Coated board (thin) 200 to 350
5 or less 0.50
Fluorescent Vinyl 350 to 450
ZEC-U3075
Coated board (thick) 250 to 400
5 or less 0.75
Fluorescent Vinyl 350 to 450
*1 The faster the cutting speed, the worse the image quality, so you have to adjust the speed to match the required image
quality.
MEMO
When uncut areas remain even when the blade force is increased to a value that is 50 to 60 gf higher than the values
shown in this chart, replace the blade.
RELATED LINKS
・ P. 37 "Performing a Cutting Test"
・ P. 39 "Adjusting the Cutting Conditions"
・ P. 138 "Replacing the Blade"
Recommended Cutting Conditions
36 Preparations before Cutting Output

Roland Camm-1 GR2-640 Specifications

General

Model	Roland Camm-1 GR2-640
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Maximum Cutting Speed	1, 485 mm/s
Cutting Force	600 gf
Interface	USB 2.0, Ethernet
Maximum Cutting Area	1, 651 (W) x 50, 000 (L) mm
Blade Force	600 gf
Software Resolution	0.025 mm/step
Distance Accuracy	±0.1% of distance traveled, or ±0.1 mm
Repeatability	±0.1 mm
Alignment Accuracy for Print & Cut	±0.1 mm (0.0004 in) or less
Operating Temperature	5 to 40°C
Operating Humidity	35 to 80 % RH (no condensation)
Dimensions (with stand)	73.8 in. (W) x 28.5 in. (D) x 44.5 in. (H) (1, 875 mm (W) x 723 mm (D) x 1, 130 mm (H))
