Need help?Do you have a question about the Roland Color Camm Pro PC-60 and is the answer not in the manual?
Operating Environment| operating temperature | 15—30ºC |
|---|---|
| operating humidity | 35—70% (non-condensing) |
| acoustic noise level (printing/cutting mode) | less than 60 dB (A) |
| acoustic noise level (standby mode) | less than 40 dB (A) |
Power| power consumption at 100 V | 0.9 A |
|---|---|
| power consumption at 117 V | 0.8 A |
| power consumption at 220-240 V | 0.45 A |
Performance| acceptable media width | 50 mm—610 mm |
|---|---|
| maximum work area | 571.6 mm x 24998 mm |
| acceptable media thickness | 0.23 mm—0.06 mm |
| cutter force | 30 gf—200 gf |
| cutting speed | 10 mm/sec.—200 mm/sec. |
| printing speed | Max. 130 mm/sec. |
| cutting resolution | 0.025 mm/step |
| printing resolution | 600 dpi |
| cutting accuracy | Less than +/-0.3 % of distance traveled or +/-0.3 mm |
| registration between printing/cutting | Less than +/-0.3 mm |
System Memory| memory | 2 Mb |
|---|
Ports & Interfaces| interface type | Parallel (Centronics), Serial (RS-232C, RS-422) |
|---|---|
| transmission speed (RS-232C) | 9600, 19200 |
| transmission speed (RS-422) | 115.2 Kbps, 57.6 Kbps |
Weight and Dimensions| main unit dimensions (width x depth x height) | 1016 mm x 326 mm x 266 mm |
|---|---|
| main unit dimensions with open cover (width x depth x height) | 1016 mm x 326 mm x 355 mm |
| dimensions with stand (width x depth x height) | 1016 mm x 326 mm x 1125 mm |
| dimensions with stand and open cover (width x depth x height) | 1016 mm x 326 mm x 1214 mm |
| main unit weight | 26 kg |
| weight with stand | 45 kg |
