CUBE-40XL/CUBE-80XL: Gitarrenverstärker
CUBE-40XL CUBE-80XL
Angegebene
Ausgangsleistung
40 W 80 W
Nomineller
Eingangspegel
(bei 1kHz)
INPUT: -10dBu/1MΩ INPUT: -10 dBu/1 MΩ
AUX IN: -10 dBu AUX IN: -10 dBu
Lautsprecher 25cm (10Zoll) 30 cm (12 Zoll)
Bedienelemente
[POWER]-Taster [POWER]-Taster
[SELECT]-Taster [SELECT]-Taster
[TUNER]-Taster [TUNER]-Taster
[POWER SQUEEZER]-Taster —
<JC CLEAN-Kanal>
[VOLUME]-Regler
<JC CLEAN-Kanal>
[VOLUME]-Regler, [BRIGHT]-Taster
<LEAD-Kanal>
Typschalter (ACOUSTIC SIM, BLACK PANEL, BRIT COMBO,TWEED CLASSIC
STACK, METAL STACK, R-FIER, EXTREME, DYNA AMP), [GAIN]-Regler,
[VOLUME]-Regler
<LEAD-Kanal>
Typschalter (ACOUSTIC SIM, BLACK PANEL, DLX COMBO, BRIT COMBO,
TWEED, CLASSIC STACK, METAL STACK, R-FIER , EXTREME, DYNA AMP),
[GAIN]-Regler, [VOLUME]-Regler
<SOLO>
[SOLO]-Taster, [VOLUME]-Regler
<SOLO>
[SOLO]-Taster, [VOLUME]-Regler
<EQUALIZER>
[BASS]-Regler, [MIDDLE]-Regler, [TREBLE]-Regler
<EQUALIZER>
[BASS]-Regler, [MIDDLE]-Regler, [TREBLE]-Regler
—
<PRESENCE>
[PRESENCE]-Regler
<EFX>
[EFX]-Regler (CHORUS, FLANGER, PHASER, TREMOLO, HEAVY OCTAVE)
<EFX>
[EFX]-Regler (CHORUS, FLANGER, PHASER, TREMOLO, HEAVY OCTAVE)
<DELAY/LOOPER>
[REC/PLAY/DUB]-Taster
[DELAY/LOOPER]-Regler
[TAP/STOP]-Taster
<DELAY/LOOPER>
[REC/PLAY/DUB]-Taster
[DELAY/LOOPER]-Regler
[TAP/STOP]-Taster
<REVERB>
[REVERB]-Regler (SPRING/PLATE)
<REVERB>
[REVERB]-Regler (SPRING/PLATE)
—
[FOOT SW TYPE]-Taster
(FS-5L/FS-5U)
Anzeigen
JC CLEAN-Kanal, LEAD-Kanal, SOLO, TUNER, EFX, DELAY/LOOPER, REC/
PLAY/DUB, REVERB, POWER SQUEEZER
JC CLEAN-Kanal, LEAD-Kanal, SOLO, TUNER, EFX, DELAY/LOOPER, REC/
PLAY/DUB, REVERB
Anschlüsse
INPUT-Buchse (Klinke)
AUX-IN-Buchse (Stereo-Miniklinke)
RECORDING OUT/PHONES-Buchse (Stereoklinke)
FOOT SW-Buchse (CH SELECT, SOLO) (Stereo-Klinke)
FOOT SW-Buchse (EFX, REVERB) (Stereo-Klinke)
FOOT SW-Buchse (DELAY/REC/PLAY/DUB, TAP/STOP)
(Stereo-Klinke)
INPUT-Buchse (Klinke)
AUX-IN-Buchse (Stereo-Miniklinke)
LINE OUT-Buchse (Klinke)
RECORDING OUT/PHONES-Buchse (Stereoklinke)
EXT SPEAKER (Klinke)
FOOT SW-Buchse (CH SELECT, SOLO) (Stereo-Klinke)
FOOT SW-Buchse (EFX, REVERB) (Stereo-Klinke)
FOOT SW-Buchse (DELAY/REC/PLAY/DUB, TAP/STOP)
(Stereo-Klinke)
Stromverbrauch 43 W 75 W
Abmessungen
385 (B) x 265 (T) x 385 (H) mm
15-3/16 (B) x 10-7/16 (T) x 15-3/16 (H) Zoll
440 (B) x 265 (T) x 440 (H) mm
17-3/8 (B) x 10-7/16 (T) x 17-3/8 (H) Zoll
Gewicht 10kg/22lbs, 1oz 16kg/35lbs., 5oz.
Zubehör Bedienungsanleitung Bedienungsanleitung
Optionen Fußtaster (BOSS FS-5L, FS-5U, FS-6) Fußtaster (BOSS FS-5L, FS-5U, FS-6)
* 0dBu = 0,775Vrms
* Im Interesse der Verbesserung des Produkts können sich die technischen Daten und/oder das Erscheinungsbild dieses Geräts ohne vorherige
Ankündigung ändern.
Technische Daten

Roland CUBE-80XL Specifications

General

Power Output	80 W
Looper	80 seconds
Channels	2
Delay/Reverb	Yes
Speaker	12 inch
Effects	Chorus, Flanger, Phaser, Tremolo
Type	Guitar Amplifier
Controls	Gain, Volume, EQ, Effects Level
Connectors	Input, Foot Switch
Inputs	1/4" phone type
Outputs	RECORDING OUT jack: 1/4" phone type
COSM Amp Models	11 types
