Specifications
Locations of the Power Rating and Serial Number Labels
Product name GR-640 GR-540 GR-420
Drive system Digital control servo motor
Cutting mechanism Media-moving method
Acceptable material widths 156 to 1,802 mm 156 to 1,548 mm 156 to 1,224 mm
Separatable material width 0 to 1,750 mm 0 to 1,496 mm 0 to 1,172 mm
Usable tools Roland CAMM-1 series blade (including blades for flatbed use)
Maximum cutting speed
During cutting: 1,050 mm/sec. (all directions)
With blade raised: 1,485 mm/sec. (45° direction)
Cutting speed 10 to 1,050 mm/sec. (settable in steps of 10 mm/sec.)
Blade force 20 to 600 gf
Mechanical resolution 0.005 mm/step
Software resolution 0.025 mm/step
Distance accuracy (*1) Error of less than ±0.2% of distance traveled or 0.1 mm, whichever is greater
Repetition accuracy (*1)(*2)
(*3)
0.1 mm or less
Interface
Ethernet (automatic switching between 10BASE-T and 100BASE-TX), USB 2.0 (FULL
SPEED compliant)
Replot memory 2 MB (buffer size: 8 MB)
Command system CAMM-GLⅢ
Power supply AC 100 to 240 V ±10%, 50/60 Hz, 0.7 A
Power consumption Approx. 70 W
Operating
noise
During
operation
67 dB (A) or less
During
standby
43 dB (A) or less
External dimensions
2,165 mm (width) × 740
mm (depth) × 1,190 mm
(height)
1,910 mm (width) × 740
mm (depth) × 1,190 mm
(height)
1,650 mm (width) × 740
mm (depth) × 1,190 mm
(height)
Weight 93.5 kg (206.1 lb.) 87 kg (191.8 lb.) 78 kg (172.0 lb.)
