2. Changes to the User’s Manual
16
2. Changes to the User’s Manual
Performing the Initial Adjustment (Correcting for Misalignment in Bidirectional Printing More Precisely)
Models : LEC-300/300A/330/540, LEJ-640
Articles in the User’s Manual
* Replace the information on the following articles of the table of contents with the information found in this document.
LEC-300
“Correcting for Misalignment in Bidirectional Printing More Precisely”
LEC-300A
LEC-330
LEC-540
“Performing the Initial Adjustment (Correcting for Misalignment in Bidirectional
Printing More Precisely)”
LEJ-640
Perform the initial adjustment of this machine. This adjustment is necessary in the following cases.
• When using this machine for the rst time
• When changing the media to use
• When further correction is required to improve printing, such as when simple correction is performed for misalignment in
bidirectional printing (”Correcting for Misalignment in Bidirectional Printing” (p. 20)).
If you will change the print head height, do so before performing this adjustment.
" Included User’s Manual “Adjusting Head Height to Match Media Thickness”
1. Output a test pattern.
1.
Press .
2. Press several times to display the gure on the below.
MENU
ADJUST BI-DIR
3. Press and then to display the gure on the below.
ADJUST BI-DIR
DETAIL SETTING
4. Press to display the gure on the below.
DETAIL SETING
TEST PRINT
5. Press .
A test pattern is output.
Correcting for Misalignment in Bidirectional Printing
