Correcting for Misalignment in Bidirectional Printing
21
2. Changes to the User’s Manual2. Changes to the User’s Manual
7. Press to select a correction value.
Select a correction value for “Simple No.1” in 1 and a correction value for “Simple No.2” in 2.
To decide a Correction Value
Choose the value that produces the least misalignment of 2 lines.
When wavering between two numbers, select half value.
Simple No.1
Simple No.2
Current correction value
Current correction value
The least misalignment
8. Press to enable the setting.
9. Press in this order to go back to the original screen.
Description
This machine prints by the bidirectional mode (in which the print heads perform printing during both their outbound pass
and return pass). This printing method is called "Bidirectional Printing." This method oers the advantage of being able to
shorten output times, but subtle misalignment occurs during the outbound and return passes. The procedure to correct this
and eliminate misalignment is "Bidirectional Correction." This misalignment varies according to the print-head height and the
thickness of the media, so we recommend performing correction to match the media you're using.
LEC-300/300A/330/540
This settings also serves to correct for misalignment of the printing and cutting positions. In such cases, check or adjust this
setting.
" “Correcting Misalignment of the Printing and Cutting Positions,” and “Correcting Misalignment for Printing and Cutting
When Using Crop Marks” on included User’s Manul.
To Next Page
