Appendix
Appendix
Roland vintage effects
This is a stereo-in, stereo-out flanger that models the Roland SBF-
325 Stereo Flanger.
FEEDBACK
Amount of flanger sound returned to the input (valid only if
EFFECT MODE is set to FLANGER)
Value: 0.0–10.0
EFFECT MODE
Value
FLANGER I: Monaural mode flanger
FLANGER II: Stereo mode flanger
FLANGER III: Cross-mix mode flanger
OFF: Modulation off
CHORUS: Chorus
CH-B MOD (CH-B Modulation)
Specifies whether the channel B flanger effect will be inverted
Value: NORM, INV
CH-A
Specifies whether the channel A flanger sound will be phase-
reversed
Value: NORM, INV
CH-B
Specifies whether the channel B flanger sound will be phase-
reversed
Value: NORM, INV
EFFECT Sw (Effect Switch)
Specifies whether the effect sound will be output
Value: OFF, ON
DIRECT Sw (Direct Switch)
Specifies whether the original sound will be output
Value: OFF, ON
LEVEL
Output level
Value: 0–100
This is a phase shifter that models the Roland SPH-323 Phase
Shifter. The original was mono-in, mono-out, but this modeling is
a dual-mono design with two units in parallel. The MOD LINK Sw
allows you to use this as a stereo-in, stereo-out effect.
CENTER FREQ (Center Frequency)
Center frequency at which the phaser effect is applied
Value: 0–100
RESONANCE
Boosts the region around the center frequency specified by
CENTER FREQ
Value: 0.0–10.0
SHIFT MODE
Specifies the number of stages for the phaser
Value: 8STAGE, 4STAGE
EFFECT Sw (Effect Switch)
Specifies whether the effect sound will be output
Value: OFF, ON
DIRECT Sw (Direct Switch)
Specifies whether the original sound will be output
Value: OFF, ON
LEVEL
Output level
Value: 0–100
MOD LINK Sw (Modulation Link Switch)
Specifies whether the modulation of the two SPH-323 units will
be linked
Value: OFF, ON
CH-B MOD (CH-B Modulation)
Specifies whether the phase of the modulation for channel B
(the lower SPH-323) will be inverted
Value: NORM, INV
MODULATION
LFO1 DEPTH
LFO1 modulation depth
Value: 0.0–10.0
LFO1 RATE
LFO1 modulation rate
Value: 0–100
LFO2 DEPTH
LFO2 modulation depth
Value: 0.0–10.0
LFO2 RATE
LFO2 modulation rate
Value: 0–100
SBF-325 (STEREO FLANGER SBF-325)
SPH-323 (PHASE SHIFTER SPH-323)
