Manual
Weld Seam Detection System R4000 SND40
for Tubes, Cans and Drums
B0059001 / Rev. 2.3
Technical data
ROLAND ELECTRONIC GmbH · Otto-Maurer-Str. 17 · DE 75210 Keltern · Phone +49 (0)7236-9392-0 · Fax +49 (0)7236-9392-33
123
Pos: 107 /Schw eissnaht/Sen soren/Zubehö r/Connectio n Box/SCB-EC -S @ 0\mod _113144770 0328_501.do cx @ 916 @ 2 @ 1
9.30 Sensor Connection Box SCB-EC-S
Using eddy current probes requires use of the Sensor Connection Box SCB-EC-S. This box
contains the protective resistor for limiting the transmitter current. For the larger combination
sensors, eddy current sensors and encircling coil sensors the box is not needed.
The sensor is connected to the box with the cable belonging to the sensor. For connecting the box
to the control unit / sensor-switch-box the cable CECM18S-G is required.
Fig. 71: SCB-EC-S
Pos: 108 /Schw eissnaht/Sen soren/Zubehö r/Gummipuff er für NS9 und NS12 @ 0\mod_1 1265277189 84_501.d ocx @ 595 @ 2 @ 1
Ø20
6
2
1 2
5
3
4
Mounting hole Ø 5mm
Sensor
Control unit
75
Ø22
4
2
80
5
7
.
5
5
2
Mounting hole Ø5 mm
63
5
3
