12.2.3 Eddy current sensors
Order designation
Comment
EC9-8x60NF10-100-S
Sensor (incl. 4 pcs. rubber mount) for NF tubes; tube diameter 10 - 250 mm;
EC9-8x60NT10-100-S
Sensor (incl. 4 pcs. rubber mount) for NF tubes; tube diameter 10 - 250 mm;
12.2.4 Eddy current probes
Order designation
Comment
EC12x30IT10-100-S
Probe for round and flat material; axial type; track width 3 mm
EC20x25IT10-100-S
Probe for round and flat material; axial type; track width 10 mm
EC30x25IT10-100-S
Probe for round and flat material; axial type; track width 16 mm
EC12x40IRT10-100-S
Probe for round and flat material; radial type; track width 3 mm
EC5x30IF10-100-S
Probe for round and flat material; axial type; track width 1.5 mm
12.2.5 Encircling coil system
Order designation
Comment
EC13x25PDN50-500-S
KOMPLETT
Encircling coil system for cables and wires (cross seams);
diameter up to max. 12 mm
Pos: 131 /Schw eissnaht/ Geräte/SND40/ 12 Bestel ldaten/Rundk örper/ Zubehö r @ 0\mo d_114353 2386031_50 1.docx @ 198 1 @ 2 @ 1
12.3 Cables / Accessories
Order designation Comment
KNS9S-G
Cable for connecting the combo and leakage flux sensors to the control unit,
with straight cable socket, standard length 5 m, max. 25 m*
KNS9S-W
Cable for connecting the combo and leakage flux sensors to the control unit,
with angular cable socket, standard length 5 m, max. 25 m*
CECM18S-G
Cable for connecting the combo and eddy current sensors to the control unit,
standard length 5 m, max. 20 m*
SKNS8S
Cable for connecting the combo and leakage flux sensors to the Sensor Switch Box,
with straight cable socket and cable plug, standard length 5 m, max. 20 m*
SM18CECM18S-GG
Cable for connecting the combo and eddy current sensors to the Sensor Switch Box,
with straight cable socket and cable plug, standard length 5 m, max. 15 m*
SSB-SND40
Sensor Switch Box for connecting 2 sensors
SCB-EC-S
Sensor Connection Box for connecting the Eddy current probes
2299700
1 pcs. Rubber mount, for sensor NS9 / NS12
S0003246
1 pcs. Rubber mount, for sensor NS24
2390924
1 pcs. Ball bearing 9x24x7 mm; for pole shoe NS9 / NS12
2390822
1 pcs. Ball bearing 8x22x7 mm; for sensor element NS9 / NS12
*The total maximum cable length, especially when using the Sensor Switch Box must not be exceeded!
