Roland Soljet Pro III XJ-540 User Manual

2-43
2
2-9 MAINTENANCE PARTS LIST _ Electrical Parts
SERVO BOARD
Reference No. Parts No Description Function
Q4 15119122 TR,FET 2SJ535 MOTOR POWER SUPPLY
IC2 15189105 IC-LINEAR MTD2005 MOTOR DRIVER(Right PUMP)
IC3 15189105 IC-LINEAR MTD2005 MOTOR DRIVER(Left PUMP)
IC4 15189105 IC-LINEAR MTD2005 MOTOR DRIVER(Middle PUMP)
HEAD BOARD
Reference No. Parts No Description Function
TR6,TR8 15129121 TR, 2SA1746 OY
TR5,TR7 15129122 TR, 2SC4131 GB
TR9,TR11 15129121 TR, 2SA1746 OY
TR10,TR12 15129122 TR, 2SC4131 GB
TR22,TR24 15129121 TR, 2SA1746 OY
TR21,TR23 15129122 TR, 2SC4131 GB
TR25,TR27 15129121 TR, 2SA1746 OY
TR26,TR28 15129122 TR, 2SC4131 GB
TR38,TR40 15129121 TR, 2SA1746 OY
TR37,TR39 15129122 TR, 2SC4131 GB
TR41,TR43 15129121 TR, 2SA1746 OY
TR42,TR44 15129122 TR, 2SC4131 GB
F1 1000001053 FUSE,04533.15MR HEAD POWER FUSE (CYAN, MAGENTA)
F2 1000001053 FUSE,04533.15MR HEAD POWER FUSE (YELLOW, BLACK)
F3 1000001053 FUSE,04533.15MR HEAD POWER FUSE (LIGHT CYAN, LIGHT MAGENTA
)
TR66 15119122 TR,FET 2SJ535 HEAD POWER SUPPLY
TAKE UP BOARD
Reference No. Parts No Description Function
D9 15019104 DI D5S6M-4000 POWER SUPPLY
IC1 15199237 V.RGL L4960 SWITCHING REGULATOR
IC6 15199952 IC L6203 MOTOR DRIVER
HEATER CONTROL BOARD
Reference No. Parts No Description Function
1000001417 RELAY,S202SE2F
1000004355 RELAY,SSR AQ1208
1000001417 RELAY,S202SE2F
1000004355 RELAY,SSR AQ1208
1000001417 RELAY,S202SE2F
1000004355 RELAY,SSR AQ1208
F1 12559105 FUSE,5X20 021706.3MXP 6.3A/250
V
FUSE (PRE HEATER)
F2 12559105 FUSE,5X20 021706.3MXP 6.3A/250
V
FUSE (PRINT HEATER)
F3 12559105 FUSE,5X20 021706.3MXP 6.3A/250
V
FUSE (DRYER HEATER)
Q403
Q404
Q405
HEATER DRIVER (PRE HEATER)
HEATER DRIVER (PRINT HEATER)
HEATER DRIVER (DRYER HEATER)
TRANSISTOR for HEAD DRIVER(LIGHT MAGENTA)
TRANSISTOR for HEAD DRIVER(LIGHT CYAN)
TRANSISTOR for HEAD DRIVER(CYAN)
TRANSISTOR for HEAD DRIVER(MAGENTA)
TRANSISTOR for HEAD DRIVER(YELLOW)
TRANSISTOR for HEAD DRIVER(BLACK)
*1:When old parts are damaging, change with the board.
Revised 5
*1
*1
*1
