Roland SONAR V-STUDIO VS-100 - Setting the Compressors

50
Using the compressors and equalizers
fig.compEQ06.eps
Setting the compressors
Meaning
Changing the settings
1 Channel currently displayed Press the [COMP/EQ] button for each channel
2 Compressor bypass Use the [CURSOR/VALUE] knob to set the cursor, and then press the knob
3 Threshold Adjust each of the [THRES], [RATIO] and [GAIN] knobs
4 Compression ratio
5 Output gain
6 Attack time 1. Use the [CURSOR/VALUE] knob to set the cursor
2. Press the [CURSOR/VALUE] knob
3. Use the [CURSOR/VALUE] knob to change the value
4. Press the [CURSOR/VALUE] knob to confirm
7 Release time
