Roland SPD-20 User Manual

Front
fig. (Front Panel)
Rear
fig. (Rear Panel and Cord Hook)
Cord Hook
To prevent the disruption of power to your unit (should the plug be pulled out accidentally), and to
avoid applying undue stress to the AC adaptor jack, anchor the power cord using the cord hook, as
shown in the illustration.
21354
14 1315
6 7 8 9 10 1112
Pad 1 Pad 2 Pad 3 Pad 4
Pad 5 Pad 6 Pad 7 Pad 8
16 17 18 19 20 21 22 23 24 25
NOTE
Panel Descriptions
8

Roland SPD-20 Specifications

General

Pads	8
MIDI	Yes
Pad Type	Rubber
Power Supply	AC Adapter
Type	Electronic Drum Pad
Instruments	210
Effects	Reverb, EQ
Outputs	Headphones
