Roland VC-100UHD User Manual

32
Setup Menu List
Network
Menu item (Parameter) Value (Bold: default) Explanation
IP Address
– Shows the IP address.
Subnet Mask
– Shows the subnet mask.
Default Gateway
– Shows the default gateway.
MAC Address
– Shows the MAC address.
DHCP
Selects how to congure the IP address, subnet mask and default gateway.
When selected, press the [PAGE/CURSOR] knob.
Client
The IP address and other information needed for connecting to the network is
obtained automatically from the DHCP server of the LAN.
Static The IP address, subnet mask, and default gateway are specied manually.
Static Address
Press the [PAGE/CURSOR] knob to congure the IP address, subnet mask and default gateway manually.
IP Address
000.000.000.000–192.168.010.010–255.255.255.255
Subnet Mask
000.000.000.000–255.255.255.000–255.255.255.255
Default Gateway
000.000.000.000 –192.168.010.001–255.255.255.255
LCD
Menu item (Parameter) Value (Bold: default) Explanation
Contrast
1–16 Adjusts the contrast of this unit’s display.
Brightness
1–8–16 Adjusts the brightness of this unit’s display.
Memory
Menu item (Parameter) Value (Bold: default) Explanation
Internal Memory This recalls and saves the settings to/from internal memory.
Recall NO. 1–8 Selects the settings to recall to current memory from internal memory.
(Execute) Press the [PAGE/CURSOR] knob to recall the selected settings.
Store NO. 1–8 Selects where to save the parameter memories.
(Execute) Press the [PAGE/CURSOR] knob to save the parameter memories.
USB Memory These parameters load or save les to/from a USB ash drive.
Load Settings vc100uhd.bin Loads the le named “vc100uhd.bin” from the USB ash drive.
(Execute) Press the [PAGE/CURSOR] knob to load the le.
Save Settings vc100uhd.bin Saves the le named “vc100uhd.bin” to the USB ash drive.
(Execute) Press the [PAGE/CURSOR] knob to save the le.
Format (Execute)
Formats the USB ash drive.
When you press the [PAGE/CURSOR] knob, format is executed.
Factory Reset
Menu item (Parameter) Value (Bold: default) Explanation
Factory Reset (Execute)
Returns the settings of the unit to their factory-set state.
When you press the [PAGE/CURSOR] knob, factory reset is executed.
System Reboot
Menu item (Parameter) Value (Bold: default) Explanation
System Reboot
(Execute)
Reboot VC-100UHD.
When you hold down the [PAGE/CURSOR] knob and press the [VALUE] knob,
reboot is executed.
Information
Menu item (Parameter) Value (Bold: default) Explanation
Version
– Displays the system program version.
Uptime
– Shows how long this unit has been operating.
FPGA
– Shows the internal IC temperature.
FAN
– Shows the rotation speed (rpm) of the internal fan.
