Roland VC-100UHD - Appendix; Main Specifications

34
Appendix
Main Specications
9 Video
Processing
4:4:4 (Y/Pb/Pr), 10-bit
Formats
SDI
2160p (DCI)/59.94 Hz, 50 Hz (SMPTE ST2048)
2160p (UHD)/59.94 Hz, 50 Hz (SMPTE ST2036)
1080p/59.94 Hz, 50 Hz (SMPTE ST274)
1080i/59.94 Hz, 50 Hz (SMPTE ST274)
HDMI (*1)
2160p (DCI)/59.94 Hz, 50 Hz (CEA-861-F)
2160p (UHD)/59.94 Hz, 50 Hz (CEA-861-F)
1080p/59.94 Hz, 50 Hz (CEA-861-F)
1080i/59.94 Hz, 50 Hz (CEA-861-F)
4096 x 2160/60 Hz (CEA-861-F)
3840 x 2160/60 Hz (CEA-861-F)
2560 x 1440/60 Hz (VESA CVT Reduced blanking)
1920 x 1200/60 Hz (VESA CVT Reduced blanking)
1280 x 1024/60 Hz (VESA DMT)
1920 x 1080/240 Hz (Pixel Clock 556.8 MHz, 567.0 MHz) (*2)
1920 x 1080/144 Hz (Pixel Clock 346.54 MHz) (*2)
1920 x 1080/120 Hz (VESA CVT Reduced blanking) (*2)
1920 x 1080/60 Hz (CEA-861-F)
USB Streaming (*3) (*4) (*5) 1080p, 720p, 640 x 480
Functions
4K Scaler
FHD Down Scaler for USB Streaming
Fade to Black
Test Pattern Generator
Rotation (*6)
Flip H, V
Edge Enhancer
Motion Adaptive Deinterlacer
Color Correction
Dynamic Range Conversion
Frame Rate Conversion (up to 240 Hz)
(*1) HDCP 1.4, 2.2 supported.
(*2) Input and through output.
(*3) UVC (USB Video Class) Uncompressed Video 4:2:2 (Y/Pb/Pr), 8-bit
(*4) The video signal frame rate can be selected Full or Half of System frame rate.
(*5) Color Gamut: Rec.601, Rec.709, Dynamic Range: SDR
(*6) The following functions cannot be used at the same time. Sub Processing, Rotation, HDMI Through.
9 Audio
Processing
24 bits/48 kHz
Formats
12G-SDI Linear PCM, 24 bits/48 kHz, 16 ch (SMPTE 299M)
HDMI 4K Linear PCM, 24 bits/48 kHz, 8 ch
STREAMING Linear PCM, 16 bits/48 kHz, 2 ch (UAC (USB Audio Class))
Input Level
LINE IN -10 dBu (Maximum: +8 dBu)
AUDIO IN +4 dBu (Maximum: +24 dBu)
Input Impedance
LINE IN 38 kΩ
AUDIO IN 15 kΩ
Output Level
LINE OUT -10 dBu (Maximum: +8 dBu)
AUDIO OUT +4 dBu (Maximum: +24 dBu)
Output Impedance
LINE OUT 1 kΩ
AUDIO OUT 600 Ω
Functions
Output Level
Patchbay
Delay
Equalizer
Mastering
Test Tone Generator
