35
Appendix
9 Connectors
Input Connectors
12G-SDI IN BNC type (SMPTE 2082, 2081, 424M (SMPTE 425M-AB), 292M, 259M)
HDMI 4K IN HDMI type A
STREAMING USB type B (USB3.0)
LINE IN RCA phono type
AUDIO IN DB-25 female type (Balanced audio 2 ch)
REFERENCE IN BNC type (Black Burst (Sync to frames), Bi-Level, Tri-Level)
Output Connectors
12G-SDI OUT BNC type (SMPTE 2082, 2081, 424M (SMPTE 425M-AB), 292M, 259M)
12G-SDI THRU BNC type
HDMI 4K OUT HDMI type A
STREAMING USB type B (USB3.0)
LINE OUT RCA phono type
AUDIO OUT DB-25 female type (Balanced audio 2 ch)
REFERENCE THRU/OUT BNC type (Black Burst)
Other Connectors
USB HOST USB A type (USB2.0) (for USB ash drive)
REMOTE RJ45 type, 100BASE-TX
9 Others
Functions
EDID emulator
Genlock
Preset memory x 8
Display
Graphic LCD 256 x 64 dots
Power Supply
AC adaptor
Current Draw
2.3 A (DC 24 V)
Power Consumption
55 W
Operation
Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
210 (W) x 284.5 (D) x 43 (H) mm
8-5/16 (W) x 11-1/4 (D) x 1-3/4 (H) inches
Weight
(excluding Accessories)
2.2 kg
4 lbs 14 oz
Accessories
Owner’s Manual
Leaet “USING THE UNIT SAFELY”
AC adaptor
Power cord
Rubber feet (4 pcs.)
Rack mount angle set
DC plug stopper
* 0 dBu = 0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the Roland
website.
