INPUT STATUS A-D
The INPUT STATUS display provides information about input signals received by the
AE-7000’s A/D input converters. There are four kinds of information displayed
regarding each of the four inputs, A, B, C and D. The displayed information is explained
in the following sections.
TYPE
Shows the format of the received digital audio:
• TYPE1 —is AES/EBU-format digital audio.
• TYPE2 —is S/P DIF-format digital audio.
• “--” —means that there’s no input signal.
COPY PROTECT
COPY PROTECT reveals the presence of SCMS copy-protection in the input signal.
• On —means that SCMS copy-protection data is present in the input signal.
• Off —means that no SCMS copy-protection data is present in the input signal.
• “--” —means that there’s no input signal.
EMPHASIS
Emphasis boosts the high-frequency content of digital audio signals. If EMPHASIS is:
• On —emphasis signals are present in the digital audio.
• Off —there’s no emphasis applied to the digital audio.
• “--” —means that there’s no input signal.
SAMPLING FREQ
SAMPLING FREQ shows the sample rate of the received digital audio, from 32k to 48k.
“Unlock” is displayed if:
• there’s no signal. • there’s no master clock
• the signals are outside the supported sample frequency range.
CLOCK SOURCE
CLOCK SOURCE selects the master clock timing reference for the AE-7000. This
parameter interacts with the VS-2480’s MASTER CLOCK parameter (Page 132).
• When the VS-2480’s MASTER CLOCK parameter’s value is the R-BUS jack to
which the AE-7000 is connected, the AE-7000’s CLOCK SOURCE should be set to
INPUT A or WORD CLOCK.
• When VS-2480 MASTER CLOCK is set to INT, COAXIAL IN, OPTICAL IN, WORD
CLOCK or EXT TIME CODE, the AE-7000’s CLOCK SOURCE should be set to
R-BUS. However, if a separate word clock generator is supplying word clock
directly to the AE-7000, set the AE-7000’s CLOCK SOURCE to WORD CLOCK.
The following table explains the CLOCK SOURCE values and tells you how to set the
VS-2480’s MASTER CLOCK parameter with each AE-7000 CLOCK SOURCE value.
Turn down the volume for all connected equipment before changing the CLOCK
SOURCE value to avoid damage to your equipment.
VS2480OMUS.book 391 ページ ２００６年２月７日 火曜日 午後４時１６分

Roland VS-2480 Specifications

General

Tracks	24
Simultaneous Recording Tracks	24
Type	Digital Audio Workstation
Simultaneous Playback Tracks	24
A/D Resolution	24-bit
D/A Resolution	24-bit
Phantom Power	Yes
Effects	8
Outputs	8
Digital I/O	S/PDIF
Sampling Rate	44.1kHz, 48kHz
Display	LCD
CD-RW Drive	Built-in
