Supplemental Information
412 www.rolandus.com Roland VS-2480 Owner’s Manual
V-Studio Song/VS-2480 Project Compatibility
Recording Mode Tables
A project using the following recording modes can be converted into a VS-2480 project
using the project IMPORT operation.
*Imported VSR-mode songs are converted to MTP mode.
A project using the following recording modes can be exported as an earlier V-Studio
song using the project EXPORT operation.
*Exported MTP-mode songs are converted to VSR mode.
Parameter Translations
The VS-2480’s parameters differ from those found in earlier V-Studios. The following
tables list the correspondence of VS-2480 parameters to earlier V-Studio parameters.
Level Values
When an earlier V-Studio’s song is imported, and when a VS-2480 project is exported,
level values are translated as follows.
Recording mode: VS-1880: VS-1680: VS-890/VSR880: VS-880EX: VS-880:
MTP OK OK VSR* — —
CDR OK — OK — —
M16 (MAS) OK OK OK OK OK
MT1 OK OK OK OK OK
MT2 OK OK OK OK OK
LIV OK OK OK OK OK
LV2 OK O K — — —
Recording mode: VS-1880: VS-1680: VS-890/VSR880: VS-880EX: VS-880:
M24 — — — — —
MTP OK OK VSR* — —
CDR OK — OK — —
M16 (MAS) OK OK OK OK OK
MT1 OK OK OK OK OK
MT2 OK OK OK OK OK
LIV OK OK OK OK OK
LV2 OK O K — — —
Earlier V-Studio: VS-2480:
0- ∞ dB
100 0dB
127 +6dB
