Page 48 RollSeal SC-325 & SC-650 Controllers Part No 4801-5156 Rev 1-2017
15.2 SC-650 Controller
SC-650 Controls and Parts
Control Description Notes
Controller
6607-8100 SC-650-V01-0 Use with RS-600 Doors ONLY
6607-8101 SC-650-V02-0 (Includes V2 Drive) Use with RS-600 Doors ONLY
6607-8102 SC-650-V01-115-PLUS Use with RS-600 Doors ONLY
6607-8103 SC-650-V01-230-PLUS Use with RS-600 Doors ONLY
Drive Board
6407-6086 /PCB AC DriveKBVF-23D w/QA V1 (V1 Drive) Use with SC-650 Controllers ONLY
6407-6087 /PCB AC DriveKBVF-23D w/QA V2 (V2 Drive) Use with SC-650 Controllers ONLY
1902-4701 Drive Cable Assembly
Chips
3701-6071 PIC SC-650 RS Door Control V0.xx (Processor) Use with SC-650 Controllers ONLY
Fuses
3010-3001 FUSE 1.2 AMP 5mmX20mm slow blow (F1) Located on PCB 154
3010-2994 FUSE 15 AMP 1/4X1-1/4 TD
Main Fuse (Black Holder)
Use with SC-650 Controllers ONLY.
Brake Module & Rectifier
6407-6088 /PCB Brake Module DBVF vr.9598 Use with SC-650 V1 & V2
Controllers
3017-3050 /A200 Brake Rectifier Use with 230 volt AC Doors
Switches
3001-2865 Main Power Switch w/toggle tabs
Door Assembly
6407-0620 /DOOR ASSY SC-650 Use with SC-650 Controllers ONLY
