Romac Transmate TapMate - TM-XL Adapter Bells and Hubs

TAPMATE
™
XL 424 OPERATING MANUAL
31
1 3
2
4
TM-XL, ADAPTER BELL
366-05-XXXX
QTY 1
QTY 1
QTY 1
QTY 1
WASHER,304SS, 5/8 IN. MS820, .095 THK X 1-5/16 OD,
QVIV,VALVE FLANGE BOLT,LONG 5/8-11 X 3 IN. H.H.B.TAP BOLT
TM,HUB ADAPTER SEALS,10&12 IN., 5/8, PARKER #600-0002- 5/8
TM,HUB ADAPTER NUTS,10&12 IN., 5/8-11 GR. 8 HEX NUT
366-05-2160 TM-XL, 20 INCH FLANGE
ADAPTER366-05-2144 TM-XL, 18 INCH FLANGE
356-01-03
6) 366-05-01
1) 361-06-05
5) 8R211S0300
ADAPTER
366-05-2192 TM-XL, 24 INCH FLANGEADAPTER
356-03-04
371-02
2) 8FW-410
3) 350-05-80.96-57
4) 350-05-80.96-52
AD AIR DRIVE VALVE 1/2 IN. BALL VALVE
BT,EXHAUST ELBOW.
BT SLIDE GATE PIPE NIPPLE 1/2 IN. NPT DBL ENDED,1-1/2 IN. LONG,STANDARD
TM-XL, ADAPTER EXHAUST VALVE
GASKET,511- 3.00,SBR
366-05-1112 TM-XL, 14 INCH MJ ADAPTER
366-05-1128 TM-XL, 16 INCH MJ ADAPTER
366-05-1144 TM-XL, 18 INCH MJ ADAPTER
366-05-1160 TM-XL, 20 INCH MJ ADAPTER
366-05-1192 TM-XL, 24 INCH MJ ADAPTER
366-05-2112 TM-XL, 14 INCH FLANGEADAPTER
366-05-2128 TM-XL, 16 INCH FLANGEADAPTER
QTY 6
QTY 12
QTY 6
QTY 6
QTY 1
A)
B)
C)
b
5
c
a
6
TM-XL
SMALL ADAPTER HUB
(366-42)
TM-XL
LARGE ADAPTER HUB
(366-43)
366‑34 TM‑XL, HOIST RING
366‑44 TM‑XL,
ADAPTER HUB O‑RING
366‑44 TM‑XL
ADAPTER HUB
O‑RING
