PREVIEW OF INPUT STATE
The status of the inputs is signaled by circular indicators located at the screw terminals of the module
connectors.
The state of the input is determined by the color of the indicator:
RED - input violated
GREEN - input intact
COMMENTS
- ON-LINE view requires active connection via USB or GPRS connection,
- In the ON-LINE mode, the module performs its standard functions, eg sends SMS messages
when zones are violated, etc.
CONTROL OF OUTPUT STATE
This option allows you to activate module outputs. It is possible, for example, to pre-test the siren
without having to start the alarm procedure. In order to trigger a given output (according to the polarity
set in the OUTPUT tab), click on the icon with the mouse . Clicking on the icon
ends the activation of the output.
