Rosemount 1195 - Table of Contents

June 2016
2
Quick Start Guide
NOTICE
This document provides basic installation guidelines for the Rosemount1195. For comprehensive
instructions for detailed configuration, diagnostics, maintenance, service, installation, or troubleshooting
refer to the Rosemount 1195 Reference Manual
. The manual and this guide are also available electronically
on EmersonProcess.com/Rosemount
.
If the Rosemount 1195 Integral Orifice was ordered assembled to a Rosemount Pressure Transmitter, refer
to the following Quick Start Guides for information on configuration and hazardous locations certifications:
 Rosemount 3051S Quick Start Guide
 Rosemount 3051SMV Quick Start Guide
 Rosemount 3051 Quick Start Guide
 Rosemount 2051 Quick Start Guide
Process leaks may cause harm or result in death
To avoid process leaks, only use gaskets designed to seal with the corresponding flange and O-rings to seal
process connections.
Contents
Rosemount 1195 Integral Orifice Assembly
View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Location and orientation . . . . . . . . . . . . . . . . . . 4
Primary element orientation . . . . . . . . . . . . . . . 7
Primary element installation . . . . . . . . . . . . . . . 9
Preparing for operation . . . . . . . . . . . . . . . . . . 11
Product certifications . . . . . . . . . . . . . . . . . . . . 15
