1.0 Rosemount 1195 Integral Orifice Assembly View
Figure 1. Traditional Body
(1)
1. Transmitter and housing are shown for clarity purposes - only supplied if ordered.
A. Manifold
B. Gaskets
C. Studs
D. Nuts
E. Transmitter
F. Rosemount 1195 traditional body
G. Traditional orifice plate
A
B
C
D
E
F
G
