Rosemount 3051SFA - Page 100

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
92
Specifications and Reference Data
Transmitter connection platform D 1-7
8 Remote-mount SW connections (
1
/2-in.) • •
Differential pressure range
1 0 to 25 inH
2
O (0 to 62,3 mbar) • • ★
2 0 to 250 inH
2
O (0 to 623 mbar) • • ★
3 0 to 1000 inH
2
O (0 to 2,5 bar) • • ★
Static pressure range
A
(7)
None • • ★
D Absolute 0.5 to 800 psia (0,033 to 55,2 bar) — • ★
E
(8)
Absolute 0.5 to 3626 psia (0,033 to 250 bar) — • ★
J Gage -14.2 to 800 psig (-0,979 to 55,2 bar) — • ★
K
(8)
Gage -14.2 to 3626 psig (-0,979 to 250 bar) — • ★
Transmitter output
A 4–20 mA with digital signal based on HART
®
protocol • • ★
F FOUNDATION Fieldbus
™
protocol (requires PlantWeb
®
housing) • — ★
X
(9)(10)
Wireless (requires wireless options and Wireless PlantWeb housing) • — ★
Transmitter housing style
Material
Conduit entry
size
00
None (Customer-supplied electrical
connection)
N/A N/A • — ★
1A PlantWeb housing Aluminum
1
/2-14 NPT • • ★
1B PlantWeb housing Aluminum M20 ⫻ 1.5 • • ★
1J PlantWeb housing SST
1
/2-14 NPT • • ★
1K PlantWeb housing SST M20 ⫻ 1.5 • • ★
2A Junction Box housing Aluminum
1
/2-14 NPT • — ★
2B Junction Box housing Aluminum M20 ⫻ 1.5 • — ★
2E
Junction Box housing with output for remote
display and interface
Aluminum
1
/2-14 NPT • — ★
2F
Junction Box housing with output for remote
display and interface
Aluminum M20 ⫻ 1.5 • — ★
2J Junction Box housing SST
1
/2-14 NPT • — ★
Table 1. Rosemount 3051SFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
