Rosemount 3051SFA - 3051 CFC Ordering Information; Rosemount 3051 CFC Compact Flowmeter

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
126
Specifications and Reference Data
A.5 3051CFC ordering information
A.5.1 Rosemount 3051CFC Compact Flowmeter
 Compact Conditioning flowmeters reduce straight piping requirements to 2D upstream and 2D
downstream from most disturbances.
 Simple installation of Compact flowmeters between any existing raised-face flanges.
Table 7. Rosemount 3051CFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Model
(1)
Product description
3051CFC Compact Flowmeter
Measurement type
D Differential Pressure ★
Primary element technology
A Annubar averaging pitot tube ★
C Conditioning orifice plate ★
P Orifice plate ★
Material type
S 316 SST ★
Line size
005
(2)
1
/2-in. (15 mm) ★
010
(2)
1-in. (25 mm) ★
015
(2)
1
1
/2-in. (40 mm) ★
020 2-in. (50 mm) ★
030 3-in. (80 mm) ★
040 4-in. (100 mm) ★
060 6-in. (150 mm) ★
080 8-in. (200 mm) ★
100
(3)(4)
10-in. (250 mm) ★
120
(3)(4)
12-in. (300 mm) ★
Primary element type
N000 Annubar sensor size 1 ★
N040 0.40 Beta ratio ★
N065
(5)
0.65 Beta ratio ★
Temperature measurement
0 No temperature sensor ★
R Remote thermowell and RTD
T
(6)
Integral temperature
