Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
124
Specifications and Reference Data
Sensor fill fluid and O-ring options
L1
(19)
Inert sensor fill fluid (silicone fill fluid is standard) ★
L2 Graphite-filled (PTFE) O-ring ★
LA
(19)
Inert sensor fill fluid and Graphite-filled (PTFE) O-ring ★
Shipboard approvals
(19)
SBS American Bureau of Shipping ★
SLL
(20)
Lloyds Register (LR) ★
Display and interface options
M4
(21)
LCD display with Local Operator Interface ★
M5 LCD display ★
Transmitter calibration certification
Q4 Calibration certificate for transmitter ★
Quality certification for safety
(16)
QS Prior-use certificate of FMEDA data ★
QT Safety certified to IEC 61508 with certificate of FMEDA ★
Transient protection
(19)(22)
T1 Transient terminal block ★
Manifold for Remote Mount option
F2 3-Valve Manifold, Stainless Steel ★
F6 5-Valve Manifold, Stainless Steel ★
F1 3-Valve Manifold, Carbon Steel
F3 3-Valve Manifold, Alloy C-276
F5 5-Valve Manifold, Carbon Steel
F7 5-Valve Manifold, Alloy C-276
Lower power output
C2 0.8-3.2 Vdc output with digital signal based on HART Protocol (Available with Output code M only) ★
Alarm levels
(16)
C4 NAMUR alarm and saturation levels, high alarm ★
CN NAMUR alarm and saturation levels, low alarm ★
CR Custom alarm and saturation signal levels, high alarm
CS Custom alarm and saturation signal levels, low alarm
CT Rosemount standard low alarm
Table 6. Rosemount 3051CFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
