Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
145
Specifications and Reference Data
Options (include with selected model number)
Extended product warranty
WR3 3-year limited warranty ★
WR5 5-year limited warranty ★
Installation accessories
AB ANSI alignment ring (150#) (only required for 10-in. [250 mm] and 12-in. [300mm] line sizes) ★
AC ANSI alignment ring (300#) (only required for 10-in. [250 mm] and 12-in. [300mm] line sizes) ★
AD ANSI alignment ring (600#) (only required for 10-in. [250 mm] and 12-in. [300mm] line sizes) ★
DG DIN alignment ring (PN16) ★
DH DIN alignment ring (PN40) ★
DJ DIN alignment ring (PN100) ★
JB JIS alignment ring (10K)
JR JIS alignment ring (20K)
JS JIS alignment ring (40K)
Remote adapters
FE Flange adapters 316 SST (
1
/2-in NPT) ★
High temperature application
HT Graphite valve packing (T
max
= 850 °F)
Flow calibration
WC
(9)
Flow calibration, 3 Pt, Conditioning orifice option C (all pipe schedules)
WD
(10)(11)
Flow calibration, 10 Pt, Conditioning option C (all schedules), Annubar option A (schedule 40)
Pressure testing
P1 Hydrostatic testing with certificate
Special cleaning
P2
(12)
Cleaning for special services
PA Cleaning per ASTM G93 level D (Section 11.4)
Special inspection
QC1 Visual and dimensional inspection with certificate ★
QC7 Inspection and performance certificate ★
Transmitter calibration certification
Q4 Calibration certificate for transmitter ★
Quality certification for safety
QS
(13)
Prior-use certificate of FMEDA data ★
QT
(14)
Safety certified to IEC 61508 with certificate of FMEDA ★
Table 12. Rosemount 2051CFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
