Specifications and Reference Data
Mounting type
A3 300# RF ANSI ★
A6 600# RF ANSI ★
D1 DN PN16 flange ★
D3 DN PN40 flange ★
D6 DN PN100 flange ★
A9
(4)
900# RF ANSI
AF
(4)
1500# RF ANSI
AT
(4)
2500 # RF ANSI
R1 150# RTJ flange
R3 300# RTJ flange
R6 600# RTJ flange
R9
(4)
900# RTJ flange
RF
(4)
1500# RTJ flange
RT
(4)
2500# RTJ flange
Opposite side support or packing gland
0
No opposite side support or packing gland (required for Pak-Lok, Flange-Lok, and Threaded
models)
★
Opposite side support – required for flanged models
C NPT threaded opposite support assembly – extended tip ★
D Welded opposite support assembly – extended tip ★
Packing gland – required for Flo-Tap models
Packing gland material
Rod material Packing material
J
(5)
Stainless Steel packing gland/cage nipple Carbon Steel PTFE
K
(5)
Stainless Steel packing gland/cage nipple Stainless Steel PTFE
L
(5)
Stainless Steel packing gland/cage nipple Carbon Steel Graphite
N
(5)
Stainless Steel packing gland/cage nipple Stainless Steel Graphite
R Alloy C-276 packing gland/cage nipple Stainless Steel Graphite
Isolation valve for Flo-Tap models
0
(2)
Not applicable or customer supplied ★
1 Gate valve, Carbon Steel
2 Gate valve, Stainless Steel
5 Ball valve, Carbon Steel
6 Ball valve, Stainless Steel
Table 14. Rosemount 485 Annubar Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
