Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
209
Specifications and Reference Data
44 3-in. – 600# 5.38 (136.7) 12.00 (304.8) 3.90 (99.1)
44 DIN80/PN16 3.85 (97.8) 9.77 (248.2) 3.90 (99.1)
44 DIN80/PN40 4.16 (105.7) 10.23 (259.8) 3.90 (99.1)
44 DIN80/ PN100 4.95 (125.7) 11.34 (288.8) 3.90 (99.1)
44 4-in. – 900# 8.19 (208.8) 15.32 (389.1) 6.40 (162.6)
44 4-in. – 1500# 8.56 (217.4) 16.07 (408.2) 6.40 (162.6)
44 4-in. – 2500# 11.19 (284.2) 19.57 (497.1) 6.40 (162.6)
Dimensions are in inches (millimeters).
Table 51. 585 Flanged with Opposite Side Support Dimensional Data
Sensor size Flange size and rating A ± 0.125 (3.2) B ± 0.25 (6.4) F (Max)
