MODEL 396P and 396PVP SECTION 7.0
TROUBLESHOOTING
TABLE 7-3. Model 396P and 396PVP pH/ORP Replacement Parts and Accessories
PN DESCRIPTION QUANTITY
11275-01 Sensor Handrail Mounting Assembly
2002011 Flow Cell, CPVC, 1 inch FNPT
23242-02 Mounting Adapter, Insertion, 1¼-inch MNPT (304 S.S.) X 1” FNPT (PEEK)
23309-03 Junction Box, for remote preamplifier Code-50
23309-04 Junction Box, for remote preamplifier Code-54
23646-01 Cable, Extension (Prepped) for Models 54, 81, 3081, and 4081
23555-00 Junction Box with preamplifier, Models 54, 81, 3081, and 4081 compatible
23557-00 Preamplifier, remote for Junction Box, Models 54, 81, 3081, and 4081 compatible
22698-00 Preamplifier, Plug-in, Model 1003 compatible (for Code 02-50) 1
22698-02 Preamplifier, Plug-in, Models 1181 and 1050 compatible (for Code 02-50) 1
22698-03 Preamplifier, Plug-in, Models 1054, 1054A, 1054B, 2054, and 2081 compatible (for Code 02-54) 1
22719-02 Junction Box, w/o Preamplifier
33081-00 Adapter Insert, PEEK, 1 X 3/4-inch, for 23242-02
7901631 Shroud, PVC
9200254 Cable, 4 conductor, 22 AWG, shielded pair, for 1054/A/B, 2054, and 1181
9200273 Cable, Extension (Unprepped) for Models 54, 81, 3081, and 4081
23645-06 15 ft (4.6 m) cable with mating VP connector with BNC on transmitter end
23645-07 15 ft (4.6 m) cable with mating VP connector with bare wires on transmitter end
9210012 Buffer Solution, 4.01pH, 16 oz 4
9210013 Buffer Solution, 6.86pH, 16 oz 4
9210014 Buffer Solution, 9.18pH, 16 oz 4
9322014 Union, KYNAR
1
9330022 Union, CPVC
9120516 BNC Adapter
915240-04 Tee, Flow-through, 2” PVC, 1” NPT
9550175 O-ring for Mounting Adapter (23242-02)
R508-160Z ORP Standard Solution, 460mV ±10 at 20°C
23550-00 Junction Box with Extension Board, Models 54, 81, 3081, and 4081 compatible
661-898695 Cable 5 Conductor (for Model 2700 only)
