Rosemount 751 - Store the Information; Set the Display Equivalent to a 4 Ma Signal; Set the Display Equivalent to a 20 Ma Signal; Replace the Cover

12
Reference Manual
00809-0100-4378, Rev CE
Section 2: Installation
February 2014
Installation
2.3.3 Store the information
1. Press both configuration buttons simultaneously for two seconds.
Note
The meter displays “- -” for approximately 7.5 seconds while the information is being stored.
2.3.4 Set the display equivalent to a 4 mA signal
1. Press the left configuration button for two seconds.
2. To decrease the display numbers, press the left configuration button. To increase the
numbers, press the right configuration button. Set the numbers between –999 and
1000.
3. To store the information, simultaneously press both configuration buttons for two
seconds.
2.3.5 Set the display equivalent to a 20 mA signal
1. Press the right configuration button for two seconds.
2. To decrease the display numbers, press the left configuration button. To increase the
numbers, press the right configuration button. Set the numbers between –999 and
9999.
Note
The sum of the 4 mA point and the span must not exceed 9999.
3. To store the information, simultaneously press both configuration buttons for two
seconds. The LCD display is now configured.
2.3.6 Replace the cover
1. Make sure the rubber gasket is seated properly, and thread the transparent housing
cover onto the LCD display body.
