16
Reference Manual
00809-0100-4378, Rev CE
Appendix A: Reference Data
February 2014
Reference Data
A.3 Analog meter specifications
A.3.1 Functional specifications
Input signal
4–20 mA dc
10–50 mA dc
40–200 mV
Note
Maximum series resistance is ten ohms for ammeters.
Meter indication
0 to 100% linear scale
0 to 100% flow scale
Special optional ranges
Overload limitation
150% of rated end scale value for two minutes
Temperature limits
-40 to 65 °C (–40 to 150 °F)
Humidity limits
0 to 100% relative humidity
Zero adjustment
Adjustment screw on face of meter
A.3.2 Performance specifications
Indication accuracy
±2% of calibrated span
Temperature effect
Less than 2% of full scale at any point within the temperature limits
A.3.3 Physical specification
Meter size
2
1
/4-inch diameter face with 2-inch long scale
