Rosemount 751 - Reference Data; Housing Specifications

Reference Manual
00809-0100-4378, Rev CE
Appendix A: Reference Data
February 2014
13Reference Data
Appendix A Reference data
Housing specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13
LCD display specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 14
Analog meter specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 16
Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 17
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 18
A.1 Housing specifications
A.1.1 Physical specifications
Materials of construction
Enclosure
Low-copper aluminum
Paint
Polyurethane
O-rings
Buna N
Meter mounting materials
Noryl
®
plastic
Electrical connections
3-pole terminal block with 8–32 nickel-plated brass screw terminals, with
3
/4–14 NPT conduit.
(Stainless steel
3
/4- to
1
/2-inch reducer available as an option.)
Enclosure rating
NEMA Type 4x. CSA Type 4x. IP66.
Weight
Indicator only: 1.8 kg (4 lb)
Indicator with optional mounting bracket: 2.27 kg (5 lb)
