Rosemount 751 - Dimensional Drawings

17
Reference Manual
00809-0100-4378, Rev CE
Appendix A: Reference Data
February 2014
Reference Data
A.4 Dimensional drawings
Figure A-1. Dimensional Drawing
Dimensions are in inches (millimeters).
3.75
(95)
2.8
(71)
5.0
(127)
6.0
(152)
4.1
(104)
.37 (9.4) Diameter Holes
(typically four places)
Optional
Mounting
Bracket
7.0
(178)
4.2
(107)
1.0
(25)
3.0
(76)
4.0
(102)
1.1
(28)
Optional
Mounting
Bracket
Permanent
Tag
FM or CSA Tag
(if required)
3/4-14 NPT
Conduit
Connection
2-in. Pipe
