Technical description
- 30 -
Digiview
5 Technical description
5.1 Digiview
5.1.1 Main display
All important basic informations about the pump pressure governor are
shown in the main display of the Digiview. The pump pressure is shown and
simultaneously a graphic shows the actual pump pressure and the adjusted
pump pressure.
Main display Digiview
Pump
The pump gauge shows the operating conditions of the pump.
There are three operating conditions of the pump.
• Pump is activated.
• Pump is deactivated.
• Pump is not ready for operation.
Pump pressure governor
The pump pressure governor gauge shows the operating conditions of the
pump pressure governor.
There are two operating conditions of the pump pressure governor.
• Pump pressure governor is activated.
EDU
EDU
EDU
USP
SVL
SVL
