Rosslare AC-215 - Reader Wiring

AC-215 Single and Double Door Access Control Unit
Hardware Installation Guide
21
AY-x11 Series Prox Readers
 AY-C11 / AY-D11
 Reading distance: 8 to 10cm
 RF modulation: ASK at 125 kHz
 For indoor use
 Slim stylish design (USA gang box)
 Bi-color light indicator
 Audible buzzer indicator (w/ Rosslare controllers)
 Built in tamper (w/ Rosslare controllers)
AY-x12 Series Prox Readers
 AY-H12 / AY-J12 / AY-K12 / AY-L12 / AY-M12
 Reading distance: 7 to 12cm
 RF modulation: ASK at 125 kHz
 For outdoor use
 Slim stylish design (UK or USA gang box, Mullion)
 Bi-color light indicator
 Includes LED control input
 Audible buzzer indicator
 Built in tamper output
