Rosslare AC-215 Hardware Installation Guide

AC-215 Single and Double Door Access Control Unit
Hardware Installation Guide
22
AY-x19 Series Pin & Prox Readers
 AY-C19 / AY-D19
 Reading distance: 8 to 10cm
 RF modulation: ASK at 125 kHz
 For indoor use
 Slim stylish design (USA gang box)
 Bi-color light indicator
 Audible buzzer indicator
 Built in tamper (w/ Rosslare controllers)
 Includes bell button (w/ Rosslare controllers)
AY-L23 RF Reader
 AY-L23
 Read range: 70 meters (200 feet)
 For outdoor use (waterproof)
 Frequency 433MHz
 Slim stylish design (Mullion)
 Bi-color LED indicator
 LED control
 Audible buzzer indicator
 Size: 145mm x 43mm x 20mm
 Used with the SA-26 wireless remote
