Rosslare AC-215 Hardware Installation Guide

AC-215 Single and Double Door Access Control Unit
Hardware Installation Guide
20
A
A
c
c
c
c
e
e
s
s
s
s
o
o
r
r
i
i
e
e
s
s
Proximity Readers
AY-x09 Series PIN Readers
 AY-C09 / AY-D09
 For indoor use
 Slim stylish design (Mullion)
 Includes LED indicator
 Audible buzzer indicator
 Built in tamper (w/ Rosslare controllers)
 Includes bell button (w/ Rosslare controllers)
AY-x11 Series Prox Readers w/ Bell
 AY-C11 / AY-D11
 Reading distance: 8 to 10cm
 RF modulation: ASK at 125 kHz
 For indoor use
 Slim stylish design (USA gang box)
 Bi-color light indicator
 Audible buzzer indicator
 Built in tamper (w/ Rosslare controllers)
 Includes bell button (w/ Rosslare controllers)

Rosslare AC-215 Specifications

General

Brand	Rosslare
Model	AC-215
Category	Gateway
Language	English
