AC-215 Single and Double Door Access Control Unit
Hardware Installation Guide
23
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
A
A
Connecting between MD-N32 (TCP/IP to serial gateway)
and AC-215
This manual is written as step by step instruction. It is very important to
Follow the right order.
Standard LAN cable - RJ45 plugs in both sides.
Hardware Requirements
Rosslare's MD-14 (RS232 to RS485 converter).
Rosslare's MD-N32 (TCP/IP to serial gateway).
Rosslare's AC-215 panel.
1. Before setting ask your network administrator for one, free IP
Topics
Address and subnet mask, which has to be used here.
2. The IP Addresses shown at the examples below are for illustration
purpose only.
1. Connect the PC using the internal network card (Mostly in the rear side
Connections-PC side
of the PC) to the LAN network with regular network cable.
(Actually if the PC is already identify and known in the local network,
it's already connects and you don't need any farther installation).
1. Connect a 9VDC adapter to the MD-N32.
Connections-AC-215 panel side
Make sure that the power LED (Red) is on.
2. Connect the MD-N32 to the LAN by using a regular network cable
through the MD-N32's RJ-45 connector.
Make sure that the link LED (Green) is on.
3. Connect MD-N32's DB9 male jack to MD-14's DB9 female jack with cross serial cable.
Connect the AC-215's RS-485 outlet to MD-14 4 wires cable.
Make sure that J1 (on the AC-215) is set to RS485 Mode.
If the jumper was not set properly, make the change, turn
the power of AC-215 off, wait few seconds and turn it on.
