AC-215 Single and Double Door Access Control Unit
Hardware Installation Guide
28
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
B
B
Connecting between MD-N33 (Modem to serial gateway)
and AC-215
This manual is written as step by step instruction. It is very important to
follow the right order.
2 Standard Telephone cables – RJ11 plugs in both sides.
Hardware Requirements
Standard Serial cable D-type 9 pin (Female connectors at both sides)
Rosslare's MD-14 (RS232 to RS485 converter).
2 Rosslare's MD-N33 (Modem to serial gateway).
Rosslare's AC-215 panel.
1. The Telephone numbers shown at the examples below are for illustration
Topics
purpose only.
2. Before permanent modem installations the modem that has to be connected to the
panel has to initialize at PC running the AxTrax AS-525 software.
1. Connect a 9VDC adapter to the first MD-N33.
Connections-PC side
Make sure that the power LED (Red) is on.
2. Connect the PC, using a free COM port, to the MD-N33 with cross serial cable.
3. Connect the MD-N33's RJ11 jack to telephone line using the Telephone
cable.
4. connect a 9VDC adapter to the second MD-N33.
Connections-AC-215 panel side
Make sure that the power LED (Red) is on.
5. Connect the MD-N33's DB11 jack to telephone wall mount using the Telephone cable.
6. Connect MD-N33's DB9 female jack to MD-14's DB9 female jack.
Connect the AC-215's RS-485 outlet to MD-14 4 wires cable.
Make sure that J1 (on the AC-215) is set to RS485 Mode.
If the jumper was not set properly, make the change, turn
the power of AC-215 off, wait few seconds and turn it on.
To Next Page
