Technical Specifications

12 AC-215IP Hardware Installation Manual

PS-14 Power Supply Specifications

Input Voltage

16 VAC, 2.42 A

Backup Battery Charger Output

12 VDC lead acid battery up to 7 Ah

To Relay Outputs – Output

Voltage 1

12 VDC,0.5 A

To Access Control Panel – Output

Voltage 2

12 VDC, 1.5 A

PS-14 Power Supply Indication

Tamper Output (open collector)

Indicates faulty power

PS-14 Power LEDs

Power In (AC) – Green LED1

Main power

Power Out (DC) – Red LED2

Low voltage

Low Battery – Red LED3

Backup battery low voltage
