AC-215IP Panel Setup

16 AC-215IP Hardware Installation Manual

Figure 5: Door Lock – Failed Open

3.4 Power Supply

Figure 6 illustrates wiring between the PS-14 power supply and the AC-215IP.

It is recommended to add a 12 VDC lead acid backup battery if the main

power supply fails. If the main output is 12 VDC, wire it to the PS-14;

otherwise support your power supply according to the output requirements.

For further information, see Section 4.3.
