5. AC-215IP Hardware Settings
Each AC-215IP panel controls an entrance. The behavior of the panel is
controlled by DIP switch settings.
Select the appropriate DIP switch setting to operate the panel as either a single
door, a double door, or four doors (see Section 5.3).
Access control panels configured as either single door or double door
controllers have two readers, IN or OUT.
Table 2 summarizes the possible hardware settings.
Table 2: Possible Hardware Settings
Single Door:
Outputs
Door Lock output (OUT 1)
General purpose output (OUT 1A)
General purpose output (OUT 2)
General purpose output (OUT 2A)
Inputs
Request to exit (IN 1)
Door monitor input (IN 1A)
General purpose input (IN 2)
General purpose input (IN 2A)
Readers
Reader1 Door Entry or Exit
Reader2 Door Exit or Entry
Double door:
Outputs
Door1 Lock output (OUT 1)
General purpose output (OUT 1A)
Door2 Lock output (OUT 2)
General purpose output (OUT 2A)
Inputs
Door1 Request to exit (IN 1)
Door1 monitor input (IN 1A)
Door2 Request to exit (IN 2)
Door2 monitor input (IN 2A)
Readers
Reader1 (Door1 IN/OUT)
Reader2 (Door2 IN/OUT)
