Installation
12 AY-Q64 Installation and Programming Manual
4.2 Wiring the AY-Q64
The reader is supplied with a 16-inch pigtail, having a 6-conductor
cable.
To connect the reader to the controller:
1. Prepare the reader cable by cutting the cable jacket back 1¼
inches and strip the wire ½ inch. Prepare the controller cable by
cutting the cable jacket back 1¼ inches and strip the wire ½ inch.
2. Splice the reader pigtail wires to the corresponding controller
wires and cover each connection (see Table 1).
Table 1: Wire Color Guide
Color Description
Red VDC
Black Ground
White Data 1/Clock
Green Data 0/Data
Brown LED control
Purple Tamper
3. If the tamper output is being utilized, connect the purple wire to
the correct input on the controller.
4. Trim and cover all conductors that are not used.
