Technical Specifications
8 AY-Q64 Installation and Programming Manual
2. Technical Specifications
Electrical Characteristics
Power Supply Type
Linear type – recommended
Operating Voltage Range
5–16 VDC
Input Current
(not including attached
devices)
Standby: 30 mA
Max: 98 mA
Card Read Distance*
2.5 in. (65 mm) maximum read range
Proximity Card Modulation
• 26-Bit Wiegand, ASK at 125 KHz
•
Clock & Data, ASK at 125 KHz
Proximity Card Compatibility
All 26-Bit EM cards
Keypad Transmit Format
• Single Key, Wiegand 6-Bit (Rosslare
Format)
• Single Key, Wiegand 6-Bit with Nibble
and Parity Bits
• Single Key, Wiegand 8-Bit, Nibbles
Complemented
• 4 Keys Binary + Facility Code, Wiegand
26-Bit
• 1 to 5 Keys + Facility Code, Wiegand
26-Bit
• 6 Keys BCD and Parity Bits, Wiegand
26-Bit
• Single Key, 3x4 Matrix Keypad
• 1 to 8 Keys BCD, Clock & Data
LED Control Input
Dry Contact, N.O.
Tamper Output
Open Collector, active low, maximum sink
current is 32 mA
* Measured using Rosslare Proximity Card (AT-14) or equivalent. Range also
depends on electrical environment and proximity to metal
