Programming the AY-Q64
16 AY-Q64 Installation and Programming Manual
6.3 Selecting Keypad Transmission Format
The AY-Q64 has eight different keypad transmission selectable
formats (see Section 6.3.1).
To select a keypad transmission format:
1. Enter Programming mode.
Press "1" to enter Menu 1.
2. The Transmit LED turns red.
Enter the appropriate option number
for the keypad transmission format that
you wish to select.
One beep is emitted on success.
The system returns to Transmit mode.
The Program LED turns off and the
Transmit LED turns red.
If an incorrect option number is entered, a long beep is sounded.
The reader returns
• Only one keypad transmission format can be active at any one time
• When using the keypad transmission format “1 to 8 keys BCD,
Clock & Data" (Option 8), an additional input is required to specify
the number of keys in the PIN code.
