6. Programming the AY-Q64
Programming the AY-Q64 is done solely via the unit's keypad driven
programming menu system. To reach the programming menu system,
the AY-Q64 must first be placed into Programming mode (see Section
6.1).
During the AY-Q64's manufacturing process, certain codes and
settings are pre-programmed. These settings are the called the default
factory settings.
Table 2 shows the names of all the AY-Q64 menus.
Default factory settings are marked by an
* sign.
Table 2: Programming Menus
Menu Description Menu Number
Selecting Keypad Transmission Format
Single Key, Wiegand 6-Bit (Rosslare Format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
1
*
Selecting Proximity Card Transmission Format
Wiegand 26-Bit
Clock & Data
Wiegand Card + PIN
2
*
Changing the Programming Code
3
Changing the Facility Code
4
Return to Factory Default Settings
0
To Next Page
