Rotabroach Element 30 Series - Page 14

Element 30 Manual Original instructions Dec 2014
14
PARTS LIST
1
RD43131
Screw M5 x 16 CSK HD
2
2
RD45607
CSK Washer
2
3
RDA3032
Guard support
1
4
RDA3031
Slide channel
1
5
RDA4201
Screw M4 x 14 BTTN HD
2
6
RDA3029
Element 30 Guard
1
7
RDA2002/1 (110) - RDA2002/3 (230)
Motor assembly
1
8
RD45624
Needle bearing HK3516
1
9
RDA3013
Bearing bracket
1
10
RDA3011/1 (110V) - RDA3011/3 (230V)
Magnet
1
11
RD4078
M8 Washer
2
12
RD4079
M8 Spring washer
2
13
RD4277
Screw M8 x 50 CAP HD
2
14
RD4095
M6 Spring washer
4
15
RD4098
Screw M6 x 20 CAP HD
4
16
RDA4005
Cable bush
1
17
RDA4021
Screw M4 x 8 BTTN HD
17
18
RDA3001
Main Housing
1
19
RD45622
Straight pin
2
20
RDA3026
Right side panel
1
21
RD4312
Grub Screw M6 x 12
5
22
RDA3092
Bush
2
23
RDA4006
Capstan Washer
2
24
RDA4004
Circlip
2
25
RDA2004
Coolant bottle assembly
1
26
RDA4029
Screw M6 x 16 CAP HD
1
27
RD33105
Gib Strip support
1
28
RDA3038
Gib strip 17.5mm
1
29
RDA3035
Slide
1
30
RD4092
M5 Shake proof washer
4
31
RD4091
Screw M5 x 22 CAP HD
4
32
RDA3027
Rack
1
33
RDA3037
Gib strip 13.5mm
1
34
RDA2016
Internal chain
1
35
RDA4204
Screw M3 x 8 CSK HD
8
36
RDA4205
M3 Nut
4
37
RDA3045
Cable chain attachment
2
38
RDA4206
Screw M4 x 12 CSK HD
2
40
RDA5008
Handle insert
1
41
RD4206
Screw M6 x 40 CAP HD
2
42
RD4069
M4 Washer
1
43
RD4068
M4 Nut
2
44
RD45604
Earth label
1
45
RDA3025
Left side panel
1
46
RDA3012
Capstan axel
1
47
RD43117
Cable clamp
1
48
RDA4207
Screw M4 x 14 CAP HD
2
49
RDA2008
Capstan arm
3
50
RDA3015
Capstan hub
1
51
RDA2020/1 (110V) - RDA2020/3 (230V)
PCB assembly
1
52
RDA2007/1 (110V) - RDA2007/3 (230V)
Control panel assembly
1
53
RDA3071 (110V) - RDA3072 (230V)
Power cable
1
54
RD4329
Safety belt
1
55
RD4088
4mm hexagonal spanner
1
56
RD43099
Chuck
1
57
RD33153
Adapter
1
58
RDA3105
Safety Glasses
1
59
RD4152
3mm hexagonal spanner
1
