Rotabroach Element 30 Series - 18) Fitting the Chuck; 19) Maintenance; Maintenance Checks

Element 30 Manual Original instructions Dec 2014
19
18) FITTING THE CHUCK
 To remove the arbor lay the machine on its side.
 Unscrew the two grub screws at the top of the arbor.
 When the arbor has become detached from the spindle this can then be removed.
 Remove the arbor support bracket and guard with the arbor retained.
 Mount the chuck using the chuck adaptor RD33153.
 Replacing the chuck is the reverse sequence.
19) MAINTENANCE
In order to ‘get the best life’ out of your Rotabroach machine always keep it in good working
order.
A number of items must always be checked on Rotabroach machines.
Always before starting any job make sure the machine is in good working order and that there
are no damaged or loose parts. Any loose parts must be tightened.
Before proceeding with any maintenance work be certain that the power supply is
disconnected.
Description
Every operation
1 week
1 Month
Visual check of
machine for damage
X
Operation of machine
X
Check brush wear
X
Check magnetic base
X
Check alignment of
the machine
X
Check grease
X
Check armature
X
Visually check the machine for damage.
The machine must be checked before operation for any signs of damage that will affect the
operation of the machine. Particular notice must be taken to the mains cable, if the machine
appears to be damaged it should not be used, failure to do so may cause injury or death.
Check operation of the machine.
The machines operation must be checked to ensure that all components are working correctly.
