4) SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 32mm dia. x 35mm deep
Arbor bore = 19.05mm (3/4") dia.
Motor Unit
Voltages
110V 50-60Hz
230V 50-60Hz
Normal full load
8 A
850 W
4 A
850 W
Electro Magnet
0.6A
69W
0.3A
69W
Size
165mm long
80mm wide
Holding Force at 20°C with 25mm
minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine MUST be used.
8000N
Total Load (magnet + motor)
919W
919W
Overall Dimensions
Height - maximum extended
410mm
Height - minimum
345mm
Width (including Capstan fitting)
165mm
Length Overall (including Guard)
270mm
Nett Weight
10.5kgs
Element 30/1
Element 30/3
Vibration total values (triax vector sum) in accordance with
EN61029-1:
Vibration emission value
(a
h
):2.273m/s
2
Uncertainty(K):1.5m/s²
Vibration emission value
(a
h
):1.935 m/s²
Uncertainty(K):1.5m/s²
Level of sound pressure in accordance with EN61029-1:
Sound pressure(LpA):
87.9 dB(A)
Acoustic power(LwA):
100.9 dB(A)
uncertainty(K)：3dB(A)
Sound pressure(LpA):
86.0 dB(A)
Acoustic power(LwA):
99.0 dB(A)
uncertainty(K)：3dB(A)
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands
when operating the machine.
These tools are UK designed and manufactured with globally sourced components and conform to the
requirements of EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in
progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
