Rotabroach Element 30 Series - Page 16

Element 30 Manual Original instructions Dec 2014
16
PARTS LIST
7.1
RD4056
Circlip
1
7.2
RA354
Button
1
7.3
RDA3016
Spring
1
7.4
RD4066
Grub Screw M8 x 8
6
7.5
RDA3019
Arbor
1
7.8
RDA3020
Arbor spindle
1
7.9
RDA3044
Flat Key
1
7.10
RDA4033
Tapping Screw ST 4.8 x 40
4
7.11
RD43304
Oil seal
2
7.12
RDA4037
Fluid elbow (black)
1
7.13
RDA3005
Gear box
1
7.14
RM22880
Needle bearing HK071109
3
7.15
RDA4208
Gear Shaft Washer 7mm ID
1
7.16
RDA3043
Spindle Gear
1
7.18
RD45614
Straight Pin
1
7.19
RD43305
Roller Bearing 6003 RS
2
7.20
RD43306
Circlip
1
7.21
RDA3041
Gear
1
7.22
RD43087
Circlip
1
7.23
RDA3006
Gear plate
1
7.24
RM17134
Roller Bearing 608 2RS
2
7.25
RDA3060/1 (110V) - RDA3060/3 (230V)
Armature
1
7.26
RDA3068
Bearing Sleeve
1
7.27
RDA5004
E30 baffle plate
1
7.28
RDA4032
Tapping Screw ST 4.2 x 50
2
7.29
9
RDA3066/1 (110V) - RDA3066/3 (230V)
Field coil
1
7.30
RDA3064
Brush cap
2
7.31
RDA3067/1 (110V) - RDA 3067/3 (230V)
Carbon brush
2
7.32
RDA3063
Brush holder
2
7.33
RDA4017
Motor cable
1
7.34
RDA4034
Tapping Screw ST 2.9 x 8
4
7.35
RDA5018
Wire box cover
1
7.36
RD45613
Screw M3 x 6 BTTN HD
4
7.37
RD35617
Terminal
2
7.38
RD43118
Capacitor
1
7.39
RDA5002
Motor housing
1
7.40
RDA5003
Top Cap
1
7.41
RDA4035
Tapping Screw ST 4.2 x 12
2
